Importing .DRI data into PHDwin V3

Importing header and production data from industry data providers is one of the most common tasks performed in PHDwin – whether to update existing cases or create new cases.

The steps below will demonstrate how to import Enervus/Drillinginfo .DRI files into PHDwin V3.

Click here for help creating the export file from the Drillinginfo Web App, DI Plus, or DI Basic.

Importing a .DRI file into PHDwin V3

Best Practice Tip: Prior to running any import, create a backup of your PHDwin project.

To do so, go to the Database Settings tab on the Ribbon. Click Database Manager. Then click the Backup button located in the upper right of the Database Manager window.

    1. From the Home ribbon, click Import. Select Import from the options list.
      Import data into PHDwin

    3. On the Import window, nagivate to and select the .DRI file you wish to import.

    5. Make the desired selection in the Options pane. This is where you can specify which Scenario you wish to add the cases to, which ID code should be used for matching to existing cases, desired behavior for when a match is not found, and whether or not to display the import log.
      Select the DRI file you wish to import

      Best Practice Tip: Change the Display Log option to Always – this is a quick way to QC your import as it will show you all cases that were imported, matched, or had an error.

    6. Make desired Import Options selections in the Import Options window. Available choices are:
      – Clear all data then import
      – Replace overlapping
      – Only append new data
      – Do not import
      DRI to PHDwin Import Options

    8. After your selections have been made, click Apply.

    10. After the import is completed,the log file will be displayed, if enabled, and you can begin working with new/update case data.
      Example log file:
      DRI to PHDwin Import Log Results

While these steps have been written for importing a DRI file specifically, they are identical or similar for importing known import files including: Accumap (.axp), Divestco (.pds), Future (.dut), GeoLogic (.glx), GeoVista (.cpd), HPDI (.hpd), IHS 298 (.98c), Lasser PRN v2 (.prn), Rextag (.rex), TGS (.tgs), WoodMackenzie (.wmc) and others.
